Key Performance
Temperature range
-65~+165
Insulation resistance
≥5000MΩ
Characteristic impedancd
50Ω
Dielectric Withstanding voltage
1000V(r ms)
Frequency range
With flexible cable
0~12.4GHz
Contact resistance
Center conductor
≤3mΩ
With semi-rigid/flexible cable
0~18GHz
Outer conductor
≤2mΩ
VSWR
With flexible cable
≤1.15+0.02F
Durability
500 Cycles
With semi-rigid/flexible cable
≤1.05+0.02F
Material And Plating
Body
Brass , gold plated or stainless steel passivated
Male center contacts
Brass , gold plated
Female center contacts
Beryllium copper , gold plated
Insulators
PTFE
Gaskets
Silicon rubber
Crimp ferrules
Copper alloy , gold or nickel plated
| Weight: | 500.0000 |
| Weight (Kg) | 500.0000 |
|---|---|
| Size | N/A |
| Material | N/A |
| Watperoof | N/A |
| Wireless | N/A |
| Battery Information | N/A |
| Package Information | N/A |
| Country of Manufacture |
